Wood Shredder

Wood Chippers

Main Features

1. Safety Features: Wood chippers typically have safety features such as emergency stop buttons, safety guards, and mechanisms to prevent kickback. Users should always follow safety guidelines when operating these machines.

2. Adjustable Settings: Some wood chippers allow users to adjust the size of the wood chips produced, which can be useful for different applications.

3. Feed Mechanism: Depending on the design, wood chippers may have different feed mechanisms, such as gravity feed, hydraulic feed, or manual feed. Hydraulic feed systems are often preferred for their efficiency and safety.

Expected Delivery in 4-10 Days
  • Product brief introduction
  • Product parameter list

Log shredder, wood crusher, mushroom wood shredder is suitable for crushing the following materials: especially suitable for crushing: miscellaneous A wood chipper, also known as a wood shredder or tree chipper, is a powerful machine designed to reduce large pieces of wood, tree branches, and other woody materials into smaller, more manageable wood chips or mulch. Wood chippers are commonly used in various industries and applications, including landscaping, forestry, recycling, and agriculture. Here’s an introduction to the key components and features of a typical wood chipper:

**Key Components:**

1. **Feed Hopper**: This is where you load the wood or branches to be chipped. The size of the hopper varies depending on the machine’s capacity.

2. **Cutting Mechanism**: Wood chippers have a cutting or chipping mechanism that consists of sharp blades, knives, or cutting disks. These components are responsible for chopping the wood into smaller pieces.

3. **Power Source**: Wood chippers can be powered by various sources, including electric motors, gasoline engines, or diesel engines. The power source drives the cutting mechanism.

4. **Chute or Discharge Port**: Processed wood chips are expelled through a chute or discharge port, and the size of the chips can often be adjusted based on the machine’s settings.

5. **Wheels or Mobility**: Many wood chippers are mounted on wheels or equipped with a towing mechanism, making them portable and easy to transport to different job sites.

**Common Uses:**

1. **Landscaping**: Wood chippers are widely used in landscaping to turn tree branches, shrubs, and other woody debris into wood chips. These chips can be used as mulch to enhance soil moisture retention and control weed growth.

2. **Forestry**: In forestry operations, wood chippers are used to process tree limbs, branches, and other wood waste generated during tree harvesting and logging activities.

3. **Recycling**: Wood chippers play a crucial role in recycling by reducing wood pallets, scrap wood, and wooden waste into smaller pieces that can be repurposed or recycled.

4. **Agriculture**: Farmers and agricultural operations may use wood chippers to process crop residues and woody material for mulching or composting.

5. **Bioenergy**: Processed wood chips can be used as a source of biomass for bioenergy production, such as in biomass boilers or pellet mills.

Wood chippers come in various sizes and capacities to accommodate different needs, from small residential models to large industrial-grade machines. The choice of a wood chipper depends on the volume and type of wood you need to process. It’s essential to operate these machines safely and according to the manufacturer’s guidelines to prevent accidents and ensure efficient wood processing.

Model ALVA-215 ALVA-216 ALVA-218 ALVA-2110 ALVA-2113 ALVA-6213
Output (t/h) 5~8 8~12 10~20 15~25 25~35 35~50
Number of blades (pieces) 2 or 3 2 or 3 3 or 4 or 5 3 or 4 or 5 3 or 4 or 5 4 or 5 or 6
Main motor (kw) 45 55 110 132~160 220 315
Feeding motor (kw) 2.2-3 3–4 4–5 7.5-11 11 11
Rotor diameter (mm) 500 650 800 1000 1300 1300
Feed port (mm) 180*400 240*540 310*680 500*1000 500*700 550*1480
Rotor speed (r/min) 590 590 650 500 500 500
Feeding speed (r/min) 38 38 38 38 38 38
Maximum raw material diameter (mm) 160 200 300 420 450 480
Wood chip size (mm) 20–35 20–35 20–35 20–35 20–35 20–35
Feed conveyor motor (kw) 2.2 4 4 11 11 11
Discharge rack motor (kw) 2.2 3 5.5 5.5 7.5 7.5
Weight (kg) 2990 4070 7200 12500 14500 18000
Overall dimensions (mm) 1540*1240*1020 1980*1950*1250 2300*2150*1500 3850*2448*2050 3850*2448*2050 3670*3300*2050
