Steam Boiler
Gas Fired Steam Boiler
Expected Delivery in 4-10 Days
- Full wet back reverse combustion chamber structure,100% butt welding, Siemens&Delixi Electronic parts, high standard, high-level quality.
- Multiple security settings, highly lower the rate of accident, guarantee the stable running of the boiler.
- Full-corrugated furnace, the fuel can be fully burned, higher thermal efficiency. Low exhaust gas temperature control, effectively reduce the loss of heat.
- Large boiler diameter，high capacity， stable steam output. Long distance between gas-water interface, low steam humidity.
| MODEL | WNS0.5 | WNS1 | WNS1.5 | WNS2 | WNS3 | WNS4 | WNS5 | WNS6 | WNS8 | ||
| Rated Output | T/H | 0.5 | 1 | 1.5 | 2 | 3 | 4 | 5 | 6 | 8 | |
| Rated Steam Pressure | MPa | 0.7/1.0/1.25 | 1.0/1.25/1.6 | 1.25/1.6 | |||||||
| Rated Steam Temperature | ℃ | 170/184/194 | 184/194/204 | 194/204 | |||||||
| Feed Water Temperature | ℃ | 20 | |||||||||
| Boiler Heating Area | SQ.M. | 13 | 30 | 35 | 53 | 77 | 107 | 127 | 198 | 212 | |
| Economizer Heating Area | SQ.M. | 10 | 12 | 12 | 12 | 15 | 22 | 30 | 35 | 45 | |
| Suitable Fuel Kind | Heavy Oil/Light Oil/Natural Gas/lpg/City Gas | ||||||||||
| Fuel Consumption | Light Oil | KG/H | 34.35 | 45-100 | 101.73 | 137.09 | 205.75 | 272.3 | 134-402 | 132-402 | 523.4 |
| Natural Gas | Nm³/H | 41.34 | 18-100 | 123.47 | 165.97 | 249.6 | 329.5 | 80-500 | 80-500 | 631.5 | |
| Equipment Power | Burn Light Oil | KW | 0.5 | 1.5 | 2.2 | 2.2 | 7.5 | 9 | 17.2 | 15 | 26 |
| Burn Gas | KW | 0.5 | 1.5 | 1.5 | 3 | 7.5 | 7.5 | 15 | 15 | 22 | |
| Max. Tranport Weight | TON | 3.5 | 6.8 | 7 | 8.2 | 9.9 | 12.7 | 14.2 | 17.5 | 21.3 | |
| Boiler Water Capacity | CBM | 1.8 | 3.6 | 4.2 | 4.9 | 8.75 | 9.3 | 9.3 | 12.1 | 15.3 | |
