Plywood Cold Press Machine

Expected Delivery in 4-10 Days
  • Product brief introduction
  • Product parameter list

1.Hydraulic station are bought from Taiwan, high stability and long service time.

2.Wuxi cylinder, no oil leakage and uniform pressure .

3.Up to Down structure, improve the plywood quality .

4.Vibration aging treatment, release the inner stress .

Configure
NAME UNIT PARAMETER
Nominal Pressure KN 4000
Board Feeding Direction The Width Direction
Structure Press from Up to Down
Opening MM 1800
Work table size MM 2700×1380
Diameter of Cylinder MM 320
Numbers of Cylinder PC 2
Hydraulic Pressure of Main Cylinder Mpa ≤26.5
Stroke of Cylinder MM 1000
Diameter of Lift Cylinder MM 63
Number of Lift Cylinder PC 2
Hydraulic Pressure of Lift Cylinder Mpa ≤16 Mpa
Stroke of Lift Cylinder MM 1000mm
Position Bottom
Unite Pressure KGF/SQCM 15.3
The flow of the Cylinder Pump L/MIN About 14
Allowed Pressure Mpa ≤26
Motor Power KW 11
Net Weight KG 13500
Overall Dimensions MM 1400x3400x4850
Control Method Automatic Pump Station
Thickness of Upper And Lower Crossbeams MM 1,000,900
Thickness of Steel Plate MM 35
Thickness of Movable Crossbeam MM 300
Thickness of Steel Plate MM 35, 20, 10
