Automatic plywood sanding machine is one of the equipments for polishing plywood and artificial board. High precision, simple operation and reliable installation.
All of our plywood machine can be customized according to your production requirement.
Sawing Machine
Automatic Sanding Machine for Plywood
Plywood machine: plywood sanding machine
Expected Delivery in 4-10 Days
1. The body of the sander is well welded by the heavy plate, steel-beam, and angle steel frame, which improve the stability of the machine.
2. The precise dynamic balance test of contact rollers, pinch rollers, and tension rollers make the sanding result precise.
3.The contact heads are capable of individual height adjustment via eccentric cams.
4. The electronic pneumatic abrasive belt oscillation system is used to control the sanding belt to move safely and stable around the contact roller.
5.The sander is equipped with an automatic brake system, which can shut down the machine immediately in an emergency.
6.Beautiful industrial outlook design.
| NAME | UNIT | PARAMETER |
|---|---|---|
| Max. Working Width | MM | 1300 |
| Working Thickness | MM | 2-100 |
| Working Length | MM | ≥750 |
| Working Accuracy | MM | ±0.1MM |
| Sanding belt size | MM | 2620*1330 |
| Sanding Belt Speed | M/S | 22.5 |
| Auto-feeding system: frequency | M/MIN | 6-35 |
| Motor for auto-feeding system | KW | 7.5 |
| Total Power | KW | 63 |
| Air Pressure | Mpa | 0.55 |
| Air Consumption | M3/MIN | 0.6 |
| Sawdust Collection Air Speed | M/S | 25-30 |
| Machine Size | MM | 2000*3080*2440 |
| Machine Weight | KG | 7000 |
