All of our plywod machines can be customized according to your production requirement.
All of our plywod machines can be customized according to your production requirement.
Main Characteristics:
Configure | ||
NAME | UNIT | PARAMETER |
Nominal Pressure | KN | 4000 |
Board Feeding Direction | The Width Direction | |
Number of Opening | Layer | 15 |
Opening Distance | MM | 70 |
Number of Hot Plate | PC | 16 |
Dimension of Hot Plate | MM | 1370x2700x42 |
Numbers of Cylinder | PC | 2 |
Diameter of Cylinder | MM | 360 |
Stroke of Cylinder | MM | 1050 |
Hydraulic Pump Pressure | MPa | ≤25 |
Unloading Closing Time | Second | About 19 |
Flow of Low Pressure Pump | L/MIN | 350×2 |
Allowed Pressure | Mpa | ≤3 |
Power | KW | 11X2 |
Flow of High Pressure Pump | L/MIN | 14 |
Power | Kw | 5.5 |
Unit Pressure | KGF/SQCM | 15.2 |
Machine Weight | KG | 38,000 |
Overall Dimensions | MM | 3600x1370x4500 |
Control Method | Automatic Pump Station | |
Frame Pattern | Assembly Frame | |
Thickness of Upper And Lower Crossbeams | MM | 900 |
Thickness of Steel Plate | MM | 40,30 |
Thickness of Steel Plate | MM | 40 |
Thickness of Acctive Crossbeam | MM | 400 |
Thickness of Steel Plate | MM | 35,20 |
Why Choose Us
FAQ
Ans.: Yes, we can customize and produce woodworking machinery according to customers’ requirements or drawings.
Ans.: We can provide you samples for quality inspection. If you order, we guarantee the quality is same with sample.
Ans.: We recommend that you come to our factory to see the goods,to verify the real situation of the products, and know more about our factory.
Ans.: The price depends on the latest prices of the raw materials.
Ans.: If you’re satisfied with the products and our service, you can sign the contract with us, pay the deposit Then we’ll produce the machines as soon as possible.
Ans.: When the product is ready, it can be delivered to you after your full payment. Will provide technical guidance.
