500T Cold Press Machine with Upper Cylinder
Expected Delivery in 4-10 Days
The plywood cold press machine is the auxiliary in the plywood production line, which is used to shorten the cycle time of the hot press and improve the quality of plywood before gluing board. Plywood cold press machine belongs to the pressing machine. Plywood cold press machine is mainly used to press the gluing veneer, so that make the initial shape, and then into the hot press machine to press. It is important to improve the quality of plywood, and it is a significant part. Plywood cold press machine in general consists of the rack, fixed beam, moving beam, the plate device, cylinder, and hydraulic system, electric control device components.
| Configure | ||
| NAME | UNIT | PARAMETER |
| Nominal Pressure | T | 500 |
| Board Feeding Direction | Transverse | |
| Rated pressure | Mpa | 26.5 |
| Working table size | MM | 1370*2700 |
| Opening | MM | 1800 |
| Main cylinders diameter | MM | 2*φ360 |
| Cylinders working stroke | MM | 1050 |
| High pressure hydraulic pump | ML/R | 25 |
| Motor power | Kw | 7.5 |
| Control Method | Full automatic and manual contro | |
| Overall Dimensions | MM | 2700*1370*3700 |
| Column width | MM | 400 |
| Upper and bottom beam height | MM | 900 |
| Middle tray height | MM | 400 |
| Frames assembly methods | bolts connected | |
| Frame main steel thickness | MM | 35 |
| Steel Model No | Q235 | |
| Total weight | KG | 12500 |
| WITH CHAIN INLET AND OUTLET DEVICE | ||
